Re: A bit quiet around here

Postby axeman » 11 Apr 2014, 19:23

i have been thinking about the bash plate for a week or so and made a mock up out of 38x38 timber, its based on the wbx engine bar which i have but could not use due to the exhaust route. once i have mocked everything up and screwed together i bought some 40mmX40mmX3mm box section and went too see ian.
the reason o have chosen 4ommX40mm is that it is the same profile as the rjes engine bar.


it is mounted where the original wbx bar mounts using the reinforced holes in the chassis rails. now i just have to form the actual bash plate which will run from the prop bars to the rjes engine mount and then too the new surport bar at the rear of the van.

neil
syncro doka 1.8 20v
User avatar
axeman

Posts: 1079
Joined: 07 Feb 2009, 19:50
Location: the kent country side
80-90 Mem No: 6410

Re: A bit quiet around here

Postby silverbullet » 11 Apr 2014, 22:23

Not bad for a tenners worth of steel and three hours if marking out, cutting and welding.
And tea drinking. Plus cake :-)
'85 syncro 'velle resto, '90 SA Microbus project, '95 SA Microbus 2.6i

http://www.025motorsport.com
User avatar
silverbullet
Trader

Posts: 10674
Joined: 08 Jun 2009, 09:51
Location: Surrey Syncronaut #156
80-90 Mem No: 6908

Re: A bit quiet around here

Postby Aidan » 12 Apr 2014, 06:45

what this thread needs is a picture of the cake as well as the metal :lol:

Metalmick8y would have had a picture of the cake set on a plate on a gingham tablecloth with a cup and saucer in the background
AIDAN
User avatar
Aidan
Trader

Posts: 4398
Joined: 11 Oct 2005, 19:21
Location: Llanfyllin, mid Wales : )
80-90 Mem No: 742

Re: A bit quiet around here

Postby silverbullet » 12 Apr 2014, 08:40

Cake was very much an engineering carve-up. Form following function :-D
'85 syncro 'velle resto, '90 SA Microbus project, '95 SA Microbus 2.6i

http://www.025motorsport.com
User avatar
silverbullet
Trader

Posts: 10674
Joined: 08 Jun 2009, 09:51
Location: Surrey Syncronaut #156
80-90 Mem No: 6908
